Quick Release
product
Quick Release
product

Quick Release

OE Number   :  BS9531; BS8562; BS9084; BS8461; BS8479; BS9527
Suitable for   :  MAN; DAF; LEYLAND
Parameters
TYPE SD NUMBER OE KNORR/WABCO PART NUMBER M α β F L VEHICLE
K24/14P2 SD06507 BS9531-II37124
BS9510-II33679
BS9510-K018094
1411742 M16*1.5 0 45 5400 15
SD06507N01 M22*1.5VOSS 90 -135 5200 15
K24/130P2 SD06513 M22*1.5VOSS 90 0
SD06513N01 BS8562
BS8560
K039066
K029501
M16*1.5 -32 -45 4867 15
K10/16P2 SD06501 M22*1.5Voss 0 45 5600 15 MAN
SD06501N01
BS9084-K001437
BS9084-K007632
81.50410.6818
81.50410.6866
32 90
SD06501N11 BS9088-K007627
81.50410.6897
81.50410.6793
-32 -90 20
K16/24P2 SD06505 M16*1.5 90 180 7800 15
K18/24P2 SD06508 M16*1.5 0 180 7800 15
SD06508N M22*1.5VOSS 90 -90
K20/24P2 SD06514 M22*1.5VOSS 90 180 7800 15
K22/24P2 SD06509 M16*1.5 90 180 7600 15
SD06509N01
BS8461-K007139
BS8463-K007141
BS9489-II39576F
1640558    1402481
ABRD108  ABRA476
-45 7600 DAF LEYLAND
K24/24P2 SD06511N01 M22*1.5VOSS 90 180 7800 15
SD06511 0 45
K14/27P2 SD06504N01 BS9270-K001903 504072793 M16*1.5 70 135 9580 15
SD06504N03 BS9265-K000978 504051705 -45 -135
K20/27P2 SD06510 BS8479-K011319 M16*1.5 -90 90 9580 15
SD06510N BS9424-II34185 99482723 30 -135
K24/30P2 SD06512 BS9536-II37747 M16*1.5 90 135 10281 15
SD06512N M22*1.5VOSS 10500 16
SD06512N01
BS9527-K017123
BS8501-K017120
1846645   1802658 M16*1.5 0 45 10281 15
SD06512N02 BS8500-K017119 1802657 M16*1.5 90 135 10281 15
SD06512N03 BS8525-K017121 1802660 M16*1.5 -55 45 10281 15
